MicroVAX 3100 Platform Options Supplement

Order Number: EK-A0519-UD

This document, the "MicroVAX 3100 Platform Options Supplement" (July 1994), provides updated information on new hardware options for MicroVAX 3100 platform systems, serving as an addendum to the main MicroVAX 3100 Platform Options manual.

The supplement details the following new SCSI-based storage options:

  • CD-ROM Drive: RRD42
  • Disk Drives: RZ24L, RZ25L, RZ26, RZ26L, RZ28
  • Tape Drives: TLZ06, TLZ07, TZK10, TZK11

For each option, the document provides:

  • A description including specifications (e.g., capacity).
  • Ordering information and component contents.
  • Instructions on setting the unique SCSI ID using jumpers or switches.
  • Detailed installation procedures specific to various MicroVAX 3100 models (e.g., Model 30, 40, 80, 85, 90, 95), including mounting and cabling.
  • Diagnostic support commands for testing the option's operation.
  • Power requirements (current and wattage).

The document also includes general cautions regarding static electricity and careful handling of components during installation. It is intended for use by personnel installing, configuring, and troubleshooting these specific options.

EK-A0519-UD-C01
July 1994
60 pages
