Rx8 Floppy Controller Engineering Drawings

This document contains the engineering drawings and supporting technical documentation for the RX8 Floppy Disk System, developed by Digital Equipment Corporation in 1975. The documentation includes:

• System Overview: An index of customer print sets, unit variations, and a block diagram illustrating the connection between the RX8 Floppy Disk System, the Floppy Disk Drive (B-DD-RX01-0), and the RX8-E Omnibus Interface (D-CS-M8357-0-1).
• Parts Lists: Detailed shipping lists and component breakdowns for various system configurations, including single and dual floppy disk systems (115V/60Hz, Low Voltage/50Hz, and High Voltage/50Hz variants).
• Technical Schematics: Wiring diagrams and interface schematics, specifically for the RX8-E Omnibus Interface module (M8357), including device selection, IOT decode, and control logic.
• Assembly Specifications: Notes regarding cable requirements (BC05L), module requirements (M8357), and instructions for installation and handling.
