3 1/2-Inch SCSI Disk Drive Installation Instructions

This document provides installation instructions for 3 1/2-inch RZ-Series SCSI disk drives into the DEC 4000 AXP Model 600 Series system.

Key points include:

• A critical caution to remove three resistor packs and two power termination jumpers from the SCSI drive before installation to prevent bus problems.
• Illustrations detailing the physical assembly of both standard and Fast SCSI drive components (e.g., data cables, terminators, bezel assemblies, SCSI ID modules, tray release latches).
• Guidance on SCSI drive selection by showing how Bus Node IDs (0-3) are assigned within the fixed-media storage tray and correspond to indicators on the system's front panel.
