HA3000 11kVA Uninterruptible Power System User's Guide

This document is the User's Guide for the Digital Equipment Corporation HA3000 11 kVA Uninterruptible Power System (UPS), 1st Edition, published December 1990.

The HA3000 is an on-line static UPS designed to protect critical electrical loads from power distribution anomalies. It features microprocessor-controlled operation, an internal diagnostic system, and modular construction. Key specifications include an 11 kVA / 8.8 kW rating, operation at 208Y/120 VAC, 3-phase, and providing approximately 10 minutes of battery backup at full load. The unit itself is substantial, weighing around 499 kg (1,100 pounds).

The guide provides comprehensive information across four main sections:

1. Introduction: Provides an overview of the system, its core components (Rectifier/Battery Charger, Static Inverter, Static Switch), and general specifications.
2. Installation: Offers detailed procedures for receiving, handling, storing, and setting up the UPS, including site prerequisites, electrical connections (AC input, output, battery), initial start-up steps, and post-installation tests (e.g., start/stop, on-battery operation, manual bypass, emergency power off). It explicitly states that electrical connections must be performed by a licensed electrician.
3. Operation: Instructs users on how to utilize the System Status and Control Panel (SS&CP) for monitoring (voltage, current, alarms) and controlling various UPS functions, covering menu navigation, programmable controls, and alarm conditions.
4. Maintenance: Provides guidance on preventive maintenance routines, general diagnostic capabilities for troubleshooting, and critical battery safety instructions.

Additionally, the document outlines Standard Features such as dry contacts interface, remote alarm/monitor panels, and optional detectors (DC ground fault, smoke). It concludes with a comprehensive Glossary of terms and dedicated Installation and Service Logs for record-keeping.
