W076b Teletype Connector

Summary This document is a technical schematic for a W076B Teletype connector circuit. The diagram depicts various electrical connections, including relays, power inputs (such as +15V and -30V), and signals for "TTY in," "TTY out," "Print," and "Keyboard." It includes passive components such as resistors (e.g., 750Ω, 1kΩ) and diodes (D1-D6), along with a 1µF 150V capacitor. A note at the bottom specifies that all capacitors are 0.1µF 100V unless otherwise stated.
