I/O Cable

Summary This document is an engineering assembly drawing for an I/O cable (BC08J-0-0). It provides the technical specifications and wiring configuration required to connect two terminal points, identified as P1 and P2.

Key features include:

• Wiring Table: Details the point-to-point connections, noting that the wiring uses 30 AWG grey wire.
• Connector Mapping: Defines the pinout arrangements for the connectors, illustrated by "View A-A" (showing the P1 pin layout) and "View B-B" (showing the P2 pin layout).
• Legend: Provides a cross-reference for specific cable model numbers (e.g., BC08J-0-06 through BC08J-0-50) and their corresponding lengths ranging from 6 feet 2 inches to 50 feet 1 inch.
• General Notes: Specifies that all connections are point-to-point (P1 to P2) and that all P1 and P2 connections are grounded.
