G614 Y Diode Matrix

Summary: The G614 module is a component featuring 256 diodes arranged into an 8x8 two-way crosspoint switching matrix, which provides 64 interconnecting points. It is designed to connect 64 cores from each of the 18 memory planes, establishing the necessary current paths for the Y axis within the core memory stack. Further technical details can be found in engineering drawings D-BS-MM15-0-6 and D-BS-MM15-0-7.
