The Omnibus Interface

This document serves as a comprehensive guide for users of the PDP-8/E computer who wish to design and build custom peripheral interfaces using the OMNIBUS system. It details the hardware considerations, signaling, and data transfer techniques necessary for effective interfacing.

Key areas covered include:

• OMNIBUS Structure: An explanation of the physical bus, including pin assignments and the elimination of traditional backplane wiring.
• System Configuration: Guidelines for system expansion, including the use of "off-the-shelf" control units and peripheral options.

• Data Transfer Facilities: A breakdown of the three primary methods for transferring data:

  • Programmed I/O Transfers: The simplest method, relying on subroutines and status flags.
  • Interrupt Facility: A more efficient method using the interrupt system for device-initiated transfers.
  • Data Break Facility: The most efficient method, allowing for high-speed direct memory access (DMA).

• Technical Specifications: Extensive signal tables (Programmed I/O, Data Break, and Basic System signals) and timing diagrams to assist the designer in ensuring electrical compatibility and correct signal timing.

• Design and Construction: Practical advice on board layout, grounding schemes, cabling, and the use of DEC modules (like M-series) to construct custom interfaces.
• Testing and Maintenance: Recommendations for initial electrical checks and system testing to identify and prevent potential faults.
• I/O Expansion: An introduction to the External Bus as a flexible alternative to the OMNIBUS, and general installation/planning considerations for PDP-8/E environments.
