Pdp-12 Relay Register Test

This document outlines the diagnostic procedures for the PDP-12 relay register. The diagnostic package consists of three separate routines:

1. Relay Flip-Flop Register Test: A major diagnostic program that exercises the relay flip-flop register on a bit-by-bit basis.
2. RSW to Relay Test: A routine that transfers the contents of the right switches (bits 6 through 11) into the relay register, acting as a visual aid for signal tracing.
3. Relay Test: A routine that cycles the relay register at a 100-millisecond rate, allowing engineers to observe and test the electromechanical characteristics of the relays using an oscilloscope.

The document provides detailed loading procedures using the binary loader, specific startup instructions for each routine, a comprehensive list of error codes that indicate specific register or relay failures, and the assembly language program listing. Appendix A also includes instructions for the PDP-8 mode "Readin Mode" (RIM) tape loader.
