DIGITAL Server 3220/3220R Series System Reference

This document is a comprehensive system reference for the DIGITAL Server 3220 (pedestal) and 3220R (rack-mount) series, covering operation, upgrade, configuration, and troubleshooting. It details the servers' high-performance, scalable features, including modular processor and storage technology, dual-channel SCSI, flexible memory architecture (up to 1GB SDRAM), and integrated I/O. The guide provides in-depth information on software utilities like ServerWORKS Quick Launch for OS installation, BIOS Setup for hardware configuration, SCSI and RAID utilities, and diagnostic software. It offers step-by-step procedures for installing and replacing server components such as processors, memory, various storage devices (including hot-swap drives), and expansion boards, along with specific configuration guidelines. Furthermore, it outlines server management capabilities, security features (both physical and BIOS-level), and extensive troubleshooting guides for common hardware and software issues. Appendices include detailed technical specifications, device mapping, and server care instructions.
