STARION 9xx & 20xx PC Family Service

This document is the Service Maintenance Manual for the Digital STARION 9xx & 20xx PC Family, published in January 1996. It serves as a comprehensive troubleshooting and repair guide primarily intended for A+ certified engineers, emphasizing that repairs should be conducted at the subassembly/module level only, not at the component level, to ensure safety and preserve warranty.

The manual covers:

• Product Overview: Describes the Starion Minitower PC models, including their Pentium CPU speeds (75MHz to 133MHz), memory configurations (8MB/16MB standard, expandable to 128MB), secondary cache, I/O slots (PCI, ISA), drive bays, hard disk sizes, video DRAM, CD-ROM, modems, and audio features.
• System Utilities & Configuration: Provides instructions on managing system software, restoring factory-installed software (both entirely and individual programs), using PHLASH.EXE for BIOS updates and crisis recovery, and configuring the BIOS Setup Utility (including main, advanced, security, power, and boot options).
• Service Procedures: Offers detailed, step-by-step guidance for safe disassembly and reassembly of the computer. This includes instructions for removing and replacing major components such as diskette drives, hard drives, expansion boards, the main logic board, power supply, CPU, video memory, and the Real-Time Clock (RTC)/Lithium Battery, along with connecting mass storage devices. Safety precautions, particularly regarding static electricity and AC power, are emphasized throughout.
• Troubleshooting: Contains extensive sections for diagnosing problems, interpreting beep codes and POST/boot messages. It includes detailed tables outlining common problems, their possible causes, and recommended actions for issues related to the computer's general operation, disk drives, monitor, CD-ROM, audio, and specific QAPlus/FE diagnostic errors.
• Technical Reference: Provides essential device mapping information, such as CPU memory addresses, I/O addresses, interrupt levels, and DMA channel assignments.
• Pass/Fail Criteria & Support: Outlines the criteria for final acceptance testing, including successful POST, QAPLUS/fe module tests, and operating system bootstrap. It also lists related documentation and online bulletin board resources for additional technical information and support.
