DIGITAL Server 7100 Series System Reference

This System Reference document serves as a comprehensive guide for the DIGITAL Server 7100 Series, detailing its operation, upgrading, configuration, and troubleshooting. It introduces the server as a high-performance, scalable network and enterprise solution, highlighting its modular processor and storage technology, ECC memory, dual-channel storage backplane, and redundant power supplies.

The document provides extensive information on essential server software and utilities, including ServerWORKS Quick Launch for OS installation, the System Configuration Utility (SCU) for hardware configuration and resource management, RAID Configuration Utility, BIOS Upgrade Utility, SCSISelect Utility, and diagnostic tools. It offers step-by-step procedures for installing and replacing internal components such as processor modules, additional memory (DIMMs), and various disk and tape drives, including hot-swap Storage Building Blocks (SBBs). Guidelines for installing and configuring ISA, EISA, and PCI expansion boards, as well as connecting SCSI and RAID adapters, are also included.

Furthermore, the guide outlines server management functions, security features like physical locks and supervisor passwords, and comprehensive troubleshooting steps for a wide array of problems related to the server, disk drives, SBBs, tape drives, monitors, CD-ROMs, diskette drives, RAID systems, and SCSI bus repeater modules. Appendices provide detailed technical specifications, device mapping information, and a complete list of SCU features, alongside recommendations for server care and relocation.
