Installing and Using the LQPX2-AA Forms Tractor

This document, "Installing and Using the LQPX2-AA Forms Tractor" (Document AA-L663A-TK), published in January 1982 by Digital Equipment Corporation (DEC), serves as a user manual for the LQPX2-AA Forms Tractor.

It provides detailed, step-by-step instructions covering:

• Installation of the Forms Tractor: Preparing the printer (LQP02 Printer) and physically installing the forms tractor.
• Inserting Paper: How to position the tractors, prepare both the printer and the forms tractor, and correctly insert continuous paper. It also includes steps for removing paper.
• Troubleshooting: A guide for common problems encountered with the forms tractor, such as poor line spacing, slanted print lines, and paper buckling, providing probable causes and corrective actions.

The manual also specifies the compatible paper types: single or multipart continuous paper with standard 0.5-inch (12.7 mm) hole spacing, a maximum total thickness of 0.020 inches (0.5 mm), and widths ranging from 1.75 to 15.75 inches (44.5 to 400.1 mm). It includes contact information for ordering additional documents and supplies.
