PCXCV-Gx Low Emission Color Monitor Install and Operating Info

This document is the "Installation and Operating Information" guide for the PCXCV-Gx Low Emission Color Monitor, published in March 1994.

It provides comprehensive details for users, covering:

1. Installation: Instructions for attaching the tilt/swivel stand and connecting the monitor to a computer, including power and signal cables. It also illustrates and explains the function of the monitor's front panel controls (e.g., V-Center, H-Size, Contrast, Brightness, Power Switch).
2. Operating Guidelines: Essential "do's" and "don'ts" for safe and proper use, such as using the supplied power cord, turning off the monitor when not in use, and crucially, warning users not to open the monitor due to hazardous high voltages.
3. Servicing & Disposal: Guidelines for cleaning the monitor (unplugging, using a damp cloth, avoiding aerosol cleaners). It explicitly warns against self-servicing and recommends using Digital's official repair services (DECmailer for mail-in, or Carry-In Service). It also advises contacting a qualified service representative for proper monitor disposal, warning of potential injury from improper disposal (implosion).
4. Specifications: Detailed technical data including:
   • Monitor type (14-inch, non-glare, 0.28 dot pitch).
   • Signal connector (15-pin D-sub), power input (autoranging 90-264 Vac).
   • Physical dimensions and weight.
   • Supported scanning modes and resolutions (e.g., 640x350 to 1024x768).
   • Power Management System: It's an "Energy Star Ready" monitor with three power-saving states (Green/On, Amber/Standby/Suspend, Off) and corresponding power consumption/recovery times.
   • Environmental Information: Highlights its "Low Emission" compliance (Swedish Standard SS436 14 90, NBOSH MPR-2), absence of harmful substances like PBDEs and Class 1 ODS, and use of recyclable, non-halogenated, cadmium-free plastics.

The document also includes regulatory compliance statements (FCC Class B, Canadian Department of Communications, VCCI Class 2) and copyright information.
